- Mains voltage supply 265Vac / 16A max. 50...60Hz
- Decoupling attenuation > 28dB
- (Surge lines - Mains lines)
- Use with NSG2050 and PNW2053B
Energy Pulse Generator System
The NSG2050 is intended for executing interference immunity tests with surge pulses as called for in IEC 801-5 and various derivatives such as IEC 1000-4-5, EN 55101-5, IEC 384-14, ANSI/IEEE C62.41, CCITT, FCC Part 68, Bellcore TR-NWT-001089, etc.
NSG2050 PULSE GENERATOR
- Pulse Voltage: 6.6 kV max
- Repetition Rate: depends on the PNW
- Phase positioning: synchronous from 0-359º or asynchronous
- Polarity: positive, negative or alternating
- Internal Impedance: depends on the PNW
- Pulse Rise Time: depends on the PNW
- Pulse Width: depends on the PNW
- Remote Control Input: RS 232 port on the rear panel
