Thermo Scientific Personal DataRAM pDR-1500

Portable Aerosol Monitor

The Thermo Scientific pDR-1500 is a portable aerosol monitor made for real-time measurement of particulate concentrations ranging from 0.001 to 400 mg/m³. It accommodates particle sizes from 0.1 to 10 µm and supports PM10, PM4, PM2.5, and PM1 measurements with interchangeable cyclones. The pDR-1500 includes an integrated sample filter for post-gravimetric validation, features environmental compensation for temperature and humidity variations, and is suitable for NIOSH Methods 0500 and 0600. It logs over 500,000 data points, including concentration, temperature, humidity, and barometric pressure, and offers USB and RS-232 connectivity for data export. With a flow rate adjustable between 1.0 and 3.5 L/min and analog output options, it supports applications in occupational health, environmental monitoring, and industrial hygiene. The pDR-1500 operates for over 24 hours on 4 AA batteries at 1.2 L/min flow.

Product Info Related Products

Measurement Range	0.001–400 mg/m³ (auto ranging)
Accuracy	±5% of reading ± precision (SAE Fine Test Dust)
Precision	Up to ±0.2% or ±0.0005 mg/m³ (at 60 sec avg)
Resolution	0.1% of reading or 0.001 mg/m³
Particle Size Response	0.1–10 µm
Cut-Point Range	1.0–10 µm (aerodynamic)
Flow Rate	1.0–3.5 L/min
Data Logging	1 sec to 1 hr intervals; >500,000 data points
Battery Life	>24 hrs @ 1.2 L/min; >6 hrs @ 3.5 L/min
Display	2-line LCD, 16 characters
Analog Output	0–2V / 4–20 mA (user-selectable scales)
Interface	USB / RS-232
Operating Temp	-10°C - 50°C
Dimensions	181 × 143 × 84 mm (7.1" × 5.6" × 3.3")
Weight	1.2 kg (41 oz)
