MB Dynamics PM250HP 250 lbf Shaker, DC - 3500 Hz

Rent MB Dynamics PM250HP 250 lbf Shaker, DC - 3500 Hz
Enlarge Image
MB Dynamics PM250HP
Request Quote Print Page
Datasheet
The MB Dynamics PM250HP 250 lbf Shaker, DC - 3500 Hz uses permanent magnet technology and the voice coil principle to create vibration. This general purpose shaker is heavy duty, industrial-quality equipment with a proven track record of lasting ten, fifteen, even over twenty years in demanding applications. The PM250HP has a 2" of stroke and a 4.1" diameter mounting table

MB Dynamics PM250HP Specs
Force Output 250 pounds Pk
Displacement 2" Pk-Pk
Velocity 60 in/sec Pk
Acceleration 80 g Pk
Frequency Range DC-3500 Hz
Cooling 80 scfm @30" H2O
Coil Current & Resistance 40 amps; 0.21 ohms
Suspension Stiffness 40 lbs/in
Stray Field - 1" over center < 40 gauss
DC Centering Drives 25 lbs to 1" Pk-Pk with 20% force derating
