Input |
Input channels |
4: all simultaneously sampled |
Input dynamic range |
>92 dB |
Maximum input |
±10V |
Voltage ranges |
27 mV to 10V full scale, 3dB steps |
Overload detection |
Full scale on all channels, analog and digital detection |
Sampling rate |
51,200 samples per second |
Output |
Output channels |
1 |
Output dynamic range |
>90 dB |
Maximum output amplitude |
± 12V peak |
Maximum output current |
16mA |
Voltage range attenuator |
Programmable 48-bit |
Sampling rate |
51,200 samples per second |
Analysis |
Frequency range (DC to) |
50, 100, 200, 500, 1000, 2000, 5000, 10000 and 20000 Hz |
Frequency resolution |
200, 400, 800, 1600, 3200, 6400 and 12800 lines |
FFT windows |
Uniform, Hanning, Blackman, Calibration, Force/impact, Hamming, Blackman-harris and Correlation |
Window Scaling |
Broadband or Narrowband |
Spectra Weighting |
Flat (None), A, B, C acoustic functions |
