Spellman’s SL150kV rack mount high voltage power supply is designed for scientific and industrial OEM applications requiring 150kV at 1200 watts in a compact cable connected standard sized rack. Models are available in positive, negative or reversible polarity. The SL150kV is fully arc and short circuit protected. Excellent regulation specifications are provided along with outstanding stability performance. The vacuum encapsulated high voltage output section assures reliable corona free operation by eliminating any concerns due to environmental factors.


Specifications:

Input: 220Vac ±10%, 50/60 Hertz
Output Voltage: 0 to 150kV
Output Polarity: Positive, negative or reversible specify at time of order
Output Current: 8mA
Output Power: 1200W
Voltage Regulation: Load: 0.01% of rated voltage for a full load change
Line: ±0.01% of rated current over specified input voltage range
Current Regulation: Load: 0.01% of rated current ±100µA for full voltage change.
Line: ±0.01% of rated current over specified input voltage range
Ripple: 0.1% peak to peak of maximum output
Temperature Coefficient: 100ppm/°C
Stability: 100ppm/hr after a 2 hour warm up, for both voltage and
current regulation
