| Voltage |
100 V setting 90 V to 110 V
120 V setting 108 V to 132 V
220 V setting 198 V to 242 V
240 V setting 216 V to 264 V |
| Frequency |
47 Hz to 440 Hz |
| Power consumption |
40 VA peak, 30 W average |
| Temperature |
Operating: 0°C to 50°C
Full accuracy: 18°C to 28°C
Storage: -20°C to 70°C |
| Warm-up |
90 mins for full uncertainty specifications |
| Relative humidity (non-condensing) |
Operating: 0°C to 28°C <90%; 28°C to 40°C <75%; 40°C to 50°C <50%
Storage: -20°C to 70°C < 95% |
| Altitude |
Operating: 2000 m
Storage: 12000 m |
| Vibration and shock |
Complies with MIL-28800F Class 3 |
| Input protection |
50 V all functions, ranges, and terminals |
| Communication |
USB-A, USB-B, RJ45, WiFi, and Bluetooth |
| Size (H x W x D) |
9.8 x 16.5 x 7.9 in (250 x 420 x 200 mm) |
| Weight |
18.5 lb. ( 8.39 kg) |
