| Range (at 23°C ambient) |
50°C to 700°C (122°F to 1292°F) |
| Display accuracy |
±0.2°C: 50°C to 425°C
±0.25°C: 425°C to 660°C |
| Stability |
±0.005°C: 50°C to 100°C
±0.01°C: 100°C to 425°C
±0.03°C: 425°C to 700°C |
| Axial uniformity |
±0.1°C: 50°C to 100°C
±0.25°C: 100°C to 425°C
±0.4°C: 425°C to 700°C |
| Radial uniformity |
±0.01°C: 50°C to 100°C
±0.025°C: 100°C to 425°C
±0.04°C: 425°C to 700°C |
| Loading effect (with a 6.35 mm reference probe and three 6.35 mm probes) |
±0.02°C at 425°C
±0.04°C at 700°C |
| Hysteresis |
0.07°C |
| Well depth |
203 mm (8 in) |
| Resolution |
0.001°C |
| Display |
LCD, °C or °F, user-selectable |
| Key pad |
Ten key with decimal and ± button. Function keys, menu key, and °C / °F key. |
| Cooling time |
235 min: 700°C to 50°C
153 min: 700°C to 100°C |
| Heating time |
46 min: 50°C to 700°C |
Dimensions
(H x W x D) |
366 x 203 x 323 mm (14.4 x 8 x 12.7 in) |
| Weight |
15 kg (33 lb.) |
| Power |
115 V AC (±10%), or
230 V AC (±10%), 50/60 Hz, 1025 W |
| Computer interface |
RS-232 Interface |
| Traceable calibration (NIST) |
Data at 100°C, 200°C, 350°C, 500°C, and 660°C |
