Amrel SPS600 DC Switching Power Supply 600V, 2A

Rent Amrel SPS600 DC Switching Power Supply 600V, 2A, 1.2kW
Enlarge Image
Rent Amrel SPS600 DC Switching Power Supply 600V, 2A, 1.2kW Rent Amrel SPS600 DC Switching Power Supply 600V, 2A, 1.2kW Rent Amrel SPS600 DC Switching Power Supply 600V, 2A, 1.2kW
Amrel SPS600
Request Quote Print Page

Specifications:


Number of Output 1
Output Ratings
 Maximum Output Voltage (V)2 600.0
 Maximum Output Current (A)3 2.0
 Maximum Output Power (W) 1200.0
Remote Programming Accuracy4
 Voltage (0.2% Vmax + 10 mV) (mV) 1210
 Current (0.3% Imax + 10 mA) (mA) 16
 Over-Voltage Protection (5% + 100 mV) (V) 30.1
Remote Programming Resolution5
 Voltage (1.1 * Vmax / 65535) (mV) 10.07
 Current (1.1 * Imax / 65535) (mA) 0.03
 OVP (1.1 * Vmax / 65535) (mV) 10.07
Remote Readback Accuracy4
 Voltage (0.2%*Vmax + 20 mV) (mV) 1220
 Current (0.3%*Imax + 20 mA) (mA) 26
Remote Readback Resolution5
 Voltage (1.1 * Vmax / 65535) (mV) 10.07
 Current (1.1 * Imax / 65535) (mA) 0.03
Local Meter Accuracy
 Voltage (0.5%*Vmax + 1 count) (mV) 3600
 Current (0.5%*Imax + 1 count) (mA) 12
Local & Ext. Analog Programming Accuracy
 Voltage and Current ± 1% Rated
Load Regulation6
 Voltage (0.02%*Vmax + 5 mV) (mV) 125
 Current (0.03%*Imax + 5 mA) (mA) 5.6
Line Regulation7
 Voltage (0.01%*Vmax + 2 mV) (mV) 62
 Current (0.01%*Imax + 2 mA) (mA) 2.2
Ripple and Noise (20Hz~20MHz)8
 Voltage RMS (rms) (mV) 40
 Voltag P-P (0 - 20 MHz, p-p) (mV) 400
Transient Response Time (mS)9 3
OVP Adjustment Range
5% - 110% of Vmax (V)
30 - 660
Programming Speed (Tup/Tdn) (mS)10 170 / 170
Temp. Cofficient11
 Constant Voltage (0.02%*Vmax / C) (mV/C) 120
 Constant Current (0.03%*Imax / C) (mA/C) 0.6
AC Input  115/230 VAC
 Frequency 50 / 60 Hz
DC Output Isolation ± 600 V
