GSSI StructureScan Mini XT GPR System

The GSSI StructureScan Mini XT is a portable ground-penetrating radar system designed for concrete inspection, offering high-resolution 2D and 3D imaging to detect rebar, conduits, and voids. It features a 2.7 GHz antenna for scanning depths up to 50 cm. (20 inches), along with a rugged, sunlight-readable touchscreen display for real-time data interpretation. The device includes multiple scanning modes, such as line and grid scans, and allows for easy data transfer via USB. Ideal for construction, utility locating, and structural evaluations, the Mini XT combines durability with advanced analysis capabilities.

Product Info Related Products

Max Depth	50 cm (20 inches)
Antenna Frequency	2700 MHz
Weight	1.8 kg (4 pounds)
Storage Capacity	14.5 GB
Optional Software	RADAN 7 for StructureScan Mini
Accessories	Palm XT Antenna, LineTrac XT, Accessory Pole

High-resolution concrete scanning and imaging
QuickScan 2D data collection at the press of a button
ScanMax accesses advanced options
Scan3D for 3D building scanning
6.5” LED Touchscreen
IP65 environmental rating
Linescan, Focus and 3D display modes
USB port available
English, French, Japanese, Chinese
Operating temperature of -4°F to 104°F (-20°C to 40°C)

Real-Time Mark and Go

SanEz Mode allows for quick mark-and-go data visualization, as in the several metallic targets pictured, which are displayed at various depths.

3D Data

Software ready for 3D imaging of structures, illustrates targets at varying depths. Two metallic bars crossing eachother within a structure are pictured.

Focus Mode

Focus Mode is a real-time GPR imaging tool which simplifies data analysis. Image shows concrete reinforcement at variable depths via focus mode.
