| Broadband Frequency Coverage |
150 kHz – 8 GHz (base configuration) |
| Antenna array |
1,218 (42 x 29) H-field probes |
| Scan area (L x W) |
31.6 x 21.8 cm (12.44 x 8.58 in) |
| Frequency accuracy of peaks |
Peak marking accuracy of spectrum analyzer |
| Measurement plane isolation |
> 20 dB |
| Maximum radiated power load |
10 W / 40 dBm |
| Maximum DUT voltage |
Glass Cover: 4kV DC; 2.6kV AC | Metal Case: 260V DC; 200V AC |
| Dimensions of the scanner (L x W x H) |
39.2 x 24.4 x 1.7 cm (L 15.43 x W 9.61 x 0.67 in) |
| Weight |
2.8 kg / 6.17 lb (including cables and the adaptor) |
