Keysight N9311X-100 Close Field Probe Set | 30 MHz - 3 GHz

The Keysight N9311X-100 is an advanced solution, designed to deliver impeccable shielding performance, ensuring RF measurements are precise and free from external interference. With the model’s robust construction and user-centric design, the N9311X-100 offers not just performance but also durability and ease of use. Whether it is for R&D, production, or quality assurance, the N9311X-100 stands as a cornerstone for achieving the highest standards in RF testing and measurement.

Product Info Related Products

Antennas

Antenna	Frequency Range	Antenna Gain	Weight	Dimensions
N9311x-500	70 to 1000 MHz	N/A	65 g	113.5 cm (full length), 19.5 cm (retracted), 10 stages
N9311x-501	700 to 2500 MHz	N/A	70 g	210 x 20 mm
N9311x-504	700 MHz-4 GHz	4 dBi	270 g	340 x200 x 25 mm
N9311x-508	680 MHz-8 GHz	5 dBi	250 g	340 x200 x 25 mm
N9311x-518	680 MHz-18 GHz	5 dBi	250 g	340 x200 x 25 mm

Bandpass Filter

Bandpass filter	3 dB Passband	Rejection	Insertion loss	VSWR
N9311X-550	814 to 850 MHz	≥36 dBc @ 740 MHz ≥36 dBc @ 915 MHz	≤0.5 dB	≤1.5
N9311X-551	880 to 915 MHz	≥35 dBc @ 862 MHz ≥35 dBc @ 932 MHz	≤1 dB	≤1.5
N9311X-552	1707.5 to 1787.5 MHz	≥35 dBc @ 1550 MHz ≥35 dBc @ 1925 MHz	≤0.4 dB	≤1.5
N9311X-553	1845 to 1915 MHz	≥35 dBc @ 1770 MHz ≥35 dBc @ 1986 MHz	≤0.6 dB	≤1.5
N9311X-554	1910 to 1990 MHz	≥35 dBc @ 1825 MHz ≥35 dBc @ 2070 MHz	≤0.6 dB	≤1.5

Frequency range: 30 MHz to 3 GHz
Measurement tool for EMI precompliance test, troubleshooting and design verification
Searches for sources of interference early in the design process

SKU: KEYS-N9311X-100
