Amplifier Research ATH800M5GA High-Gain Horn Antenna 800 MHz - 5 GHz, 1500 Watt

Rent Amplifier Research ATH800M5GA High-Gain Horn Antenna 800 MHz - 5 GHz, 1500 Watt
Enlarge Image
Amplifier Research ATH800M5GA
Request Quote Print Page
Datasheet
The Amplifier Research ATH800M5GA High-Gain Horn Antenna 800 MHz - 5 GHz, 1500 Watt is a wide band, microwave horn antenna that provides high field intensities. With a minimum gain of 13.0 dB over isotropic, the Model ATH800M5GA supplies the constant high intensity fields necessary for RFI/EMI field testing within and beyond the confines of a shielded room. Specially designed septums are installed to focus the beamwidth ensuring the intensity of the field for 3 meter testing.

The Model ATH800M5GA is compact and lightweight for ready mobility, yet is built tough enough for the extra demands of outdoor use and easily mounts on a tripod or back plate. Part of a family of microwave frequency antennas the Model ATH800M5GA provides the lower frequency microwave response required for many often used test specifications.


Amplifier Research ATH800M5GA Specifications:


Frequency Range: 0.8–5.0 GHz (M5 range is 1–3.1GHz)
Peak Input Power (maximum): 15kW peak pulse maximum (1% duty cycle 6μs pulse width)
Power Gain (over isotropic): 11 dB minimum, typically increasing to 21 dB at 5.0 GHz
Impedance: 50 ohms nominal
VSWR: Maximum: 2.5:1
Average: 1.6:1
Front to Back Ratio (minimum): 20 dB
Connector: All models come with Type N(F) quick-change
Mounting Provisions: Mounting pads on two adjacent sides for tripod and back plate. May also be tripod mounted in two perpendicular planes using optional tripod.
Weight: 7.26 kg (16 lbs)
Size (W x H x D): 46.3 x 46.3 x 69.2 cm (18.25 x 18.25 x 27.25 in
