NH Research 9300 High-Voltage Battery Test System
- Scalable to 2.4MW / 8000A
- Max Current @ 600V: 333A
- Current @ 1200V: ±167A
Pacific Power 3210AGX | AC & DC Load/Power Supply | 21 kVA
- 15 - 1200 Hz
- 1 Phase mode 125 Arms / 62.5Adc
- 0-350 Vac / 0-500 Vdc
NH Research (NI) 4800 Bidirectional Power Supply
- Fully integrated battery cycler: built-in isolation contactor relays, pre-charge circuit, reverse polarity checker
- Voltage models from 80 VDC
- Modular and scalable power
Chroma 62180D-100
- 18kW / 100V / 180A
- Bidirectional DC Power Supply
- High Speed Transient Response <1.5ms
Chroma 63804 AC/DC Electronic Load | 350 V, 45 A, 4500 W
- Parallel / 3-phase function
- Constant & rectified load modes for AC loading
- Analog voltage & current monitor
NH Research 4760 High Voltage Electronic DC Load | 600 V, 300 A
- 600 Volts, 300 Amps - Paralleling capability up to 1800 Amps or 36 kW
- 18 Voltage, Current, Power and Timing Measurements
- Complex load profile playback
Megger Torkel 950 Battery Load Unit
- Display range: 0.0 to 2999.0 A
- Basic inaccuracy: ±(0.5% of reading +0.1 A)
- Resolution: 0.1 A
ITECH IT6642C-1200-200 Programmable Bidirectional DC Power System | 1200VDC / 200A / 42kW
- Dual Channel: Allows simultaneous output with independent control.
- Bidirectional Functionality: Serves both as a power supply and an electronic load.
- Energy Recycling: Efficiently feeds energy back into the grid.
Chroma 63209 DC Electronic Load
- 15 kW
- 0 - 80 V
- Dynamic loading: <20 kHz
Megger Torkel 860 Battery Bank Load Tester
- Batteries can be tested "in service"
- Unit adjusts to include load currents in the test parameters
- User adjustable alarm and shutdown points to avoid excessive discharge
Tesco T4350 EVSE Test System
- EVSE test system
- DC current capabilities up to 350 A
- Integrated GPS system
Eagle Eye LB-480-600-CC DC Load Bank
- 480V AC
- 600A
- 60Hz
Chroma 62180D-600 Bidirectional DC Power Supply | 600 V, 18 kW
- Voltage rating of 120 to 600 V
- Current rating of 0 to 120 A
- Power rating of 18 kW
Chroma 63204 Volt DC Electronic Load
- Dynamic loading: Up to 20 kHz
- Only need 1 V to draw rated current
- Programmable slew rate, up to 41 A/µS
ITECH IT8015-80-450
- Regenerative up to 95% efficiency
- High power density and output of 15 kW with a 3U chassis, expandable up to 2 MW by paralleling
- Power accumulation function, list function, battery test function
Chroma 63206A-600-420 DC Load | 600 V, 420 A
- 600 V and 6 kW
- High precision and accuracy
- Up to 10 units master/slave parallel control
Cannon Load Banks L-48-500 Load Bank 48 VDC, 500 A
- Load Steps: 100 A, 100 A, 100 A, and 100 A fixed steps, 0 - 100 A adjustable step
- Plug test pins for connecting test leads
- Meters: 0 -75 V voltmeter, 0 - 500 A ammeter
Megger Torkel 840 DC Battery Load Tester
- "In Service" batteries can be tested
- Load currents in the test parameters are included as the unit adjusts
- Adjustable alarm and shutdown points to prevent excessive discharge
Eagle Eye LB-480-300-CC DC Load Bank
- Rated Voltage: 480V DC
- Current Capacity: 300A
- Single Phase Power Supply
Chroma 62180D-1800 Bidirectional DC Power Supply
- Two-quadrant operation: source and load functions
- High power density: 18 kW in 3 U
- Easy master/slave parallel & series, 1 operation up to 180 kW
Chroma 63212 Programmable DC Electronic Load
- Power: 10kW
- Current: 0~150A Max.
- Voltage Range: 10~1000V
Chroma 63212E-150-1200 DC Load
- Rated power: 2kW, 3kW, 4kW, 5kW, 6kW, 8kW, 10kW, 12kW, 15kW, 18kW, 20kW, 24kW
- Voltage range: 150V, 600V, 1200V
- Current range: 2000A max.
Chroma 63202A Ultra Low Voltage DC Electronic Load | 20V, 2000A, 2kW
- Rated power: 2kW
- Voltage range: 0 – 20V
- Current range: 1,000A / 2,000A
Chroma 63206 DC Electronic Load 80 V, 600 A, 10.4 kW
- CC, CR, CV, CP load modes
- Master/Slave paralleling control mode, allow synchronous load control under static and dynamic loading mode (Up to 93.6kW)
- Dynamic loading : Up to 20kHz
Kikusui PLZ6000R Regenerative Load | 6 kW
