OMICRON MPD 600 Partial Discharge Measuring System
- Center Frequency: Up to 32 MHz
- PD Event Time Resolution: < 2 ns
- Dynamic Range: PD input 132 dB
FLIR Si2-LD Acoustic Imager
- Frequency: 2kHz – 130kHz
- Detection Range: 0.3 – 200 meters
- Camera Resolution: 12 MP
CAE Software & Systems SoundCam
- Frequency Range: 10Hz - 24kHz
- Sound Pressure: Max. 120dB
- Sample Rate: 48kHz
Haefely DMI 553 Digital Measuring Instrument
- Designed to measure voltage and current in high voltage applications
- Measures AC voltage and currents as RMS, Peak and Peak/√2 among others
- Measures DC voltage and currents as Mean, Peak and ripple
Haefely DMI 552 Digital Measuring Instrument
- Designed to measure voltage and current in high voltage applications
- Measures AC voltage and currents as RMS, Peak, and Peak/√2 among others
- Measures DC voltage and currents as Mean, Peak, and ripple
Hipotronics DDX9101 Digital Partial Discharge Detector
- Settable PD threshold with indicator light when limit is exceeded
- Ethernet port for communication with PC (optional)
- Data acquisition and remote control software package
Hipotronics DDX7000 Digital Partial Discharge Detector
- Automated Testing
- Easy Operation – uses the worldwide standard Windows operating system
- Customized Report Generation – allows transfer of pulse displays and data into commonly used word processors and spreadsheets
Haefely DDX 9161 Partial Discharge Detector
- User-defined measuring band
- Unique flexible high order digital filters
- High-resolution spectrum analyzer with oscilloscope
Haefely DDX 9160 Partial Discharge Detector
- User-defined measuring band
- Unique flexible high order digital filters
- High-resolution spectrum analyzer with oscilloscope
Uvirco Technologies CoroCAM 8HD Corona Imaging Camera
- High sensitivity solar blind UV detector
- Synchronized Smooth or Stepped Zoom of all 3 camera channels
- Manual or Auto focus for Visible channel
Uvirco Technologies CoroCAM 7HD Corona Imaging Camera
- Adjustable and focusable viewfinder
- High sensitivity detector
- Motorized Solar Blind (SB) filter removal in Non-Solar Blind (NSB) mode
Uvirco Technologies CoroCAM 6HD Corona Imaging Camera
- A high sensitivity detector
- UV Gain, threshold or integration can be set to optimize the resulting image
- Automatic or Manual visible camera focus control from <0.7m to infinity
OMICRON Montesto 200 Partial Discharge Monitoring System
- 4 PD Channels
- Sample Rate: AC: 31.25 kS/s
- Frequency: AC: 5 Hz–16 kHz
Doble Spark P3 Universal PD & EMI Analyzer
- Frequency: 9kHz – 2GHz (PD)
- CISPR 16-1-2, MIL-STD-461 RE103
- Bandwidth: 500kHz (DC)
Megger UHF-PDD Partial Discharge Survey Instrument
- UHF Frequency Range: 0.15 - 1GHz
- RF Frequency Range: 0.1 - 70MHz
- Sensitivity: -90dBm
Megger MPAC128 Acoustic Imager
- 2kHz - 48kHz
- 0.3 - 120m
- 25.7 dBA - 132.5 dBA
Doble PDS100 Partial Discharge Surveyor
- 50 MHz - 1000 MHz
- 120 kHz / 6 MHz RBW
- Peak, Average, & SPAM
Sonel UV-260 Corona Camera
- High sensitivity to UV signals.
- Precise location of corona emitting sources.
- Auto focus of UV and visible channels.
EA Technology UltraTEV Locator Partial Discharge System
- Ability to pinpoint PD activity to within 10cm (4 inches)
- Ultrasonic and TEV sensors for surface and internal PD
- Factors in environmental conditions: temperature, pressure and humidity
UE Systems Ultraprobe 2000 Ultrasonic Field Tester
- Range: 20–100 kHz
- Precision 10‑turn dial
- Logarithmic & Linear
FOTRIC TD3-LD
- Part of the FOTRIC TD3 Series
- Field of view of 45°
- 96 MEMS digital microphones
Acoem Soundcam Ultra 3
- 2-in-1 acoustic and thermal imager
- 176 microphones
- Handheld and IP54 waterproof
FLIR Si2 Series
- Discharge into air
- Surface discharge
- Floating discharge
HVPD PDS Insight 2 Partial Discharge Detector
- For condition-based maintenance and substation access safety
- Handheld device with a comprehensive display
- Operating temperature of -20°C to +55°C
OMICRON PDL 650 Acoustic Partial Discharge Test System
- Portable design
- Safe operation
- Defect visualization
