The Fluke Ti20 Thermal Imager is easy to use, thanks to one-handed ‘point-and-shoot’ operation and intuitive on-screen guidance, the Ti20 Thermal Imager does not require specialist training to obtain accurate measurements. Just point at the target, focus the instrument, and it automatically adjusts the temperature range to show a crisp image. When the user pulls the trigger, the image and associated measurement data is stored. Through the software (included), key image parameters can be changed to optimize the image and extract maximum detail without going back to the factory floor.

Specifications
Features
Applications
Options
Accessories
Standards
Videos

Features

Instantly provides non-contact temperature images to quickly determine hot spots
Fully radiometric for detailed temperature analysis and tracking of critical components
Complete solution with InsideIR software for analysis, reporting and routing
Large color LCD displays uncluttered image with data and routing instructions
Uses revolutionary detector technology to provide a clear thermal image while accurately measuring the temperature
Measures up to 350 °C to cover a broad range of industrial applications
Protected against dust and moisture (IP54 rated) to withstand harsh industrial environments
Provides 3 hours continuous operation per battery charge

Specifications

Detector
Detector Type	128 x 96 uncooled focal plane array
NETD (Thermal Sensitivity)	200 mK
Thermal
Temperature Range	-10°C to 350°C (14°F to 662°F)
Accuracy	± 2°C or 2% (whichever is greater)
Optical
Field of View (FOV)	20° horizontal by 15° vertical
Optical resolution (D:S)	75:1 or better
Target Sighting	Single laser (meets IEC Class 2 & FDA Class II requirements)
Controls and Adjustments
Focus	61 cm (24 in) to infinity
Temperature Scale	°C or °F selectable
Palettes	Grayscale, reverse grayscale, rainbow, ironbow
Measurement Modes	Auto and manual level and span adjustment
LCD Backlight	Bright, dim selectable
Adjustable Emissivity	0.10 to 1.00 in 0.01 increments
Adjustable reflected background temperature	-50°C to 460°C (-58°F to 860°F)
Environmental
Ambient Operating Temperature	0°C to 50°C (32°F to 112°F)
Relative Humidity	10% to 95% non-condensing
Storage Temperature	-25°C to 70°C (-13°F to 158°F) without batteries
