ITECH IT6015C-80-450 Bidirectional DC Power Supply

80VDC / 450A / 15,000W

The ITECH IT6015C-80-450 is a bidirectional programmable DC power supply with a voltage up to 80 V, current range of 450 A, and power range up to +15 kW. It features high-efficiency SiC-based technology, regenerative energy feedback up to 95%, and supports both source and sink operation. The unit includes multiple communication interfaces, built-in waveform generation, and is suitable for applications such as battery testing, automotive electronics, and renewable energy simulation.

Product Info Related Products

Output Voltage Range	0 – 80 V
Output Current Range	-450 – 450 A
Output Power Range	-15,000 – 15,000 W
Minimum Load Resistance	0 – 0.178 Ω
Setting Resolution (V/A/W)	0.001 V / 0.01 A / 0.001 kW
Accuracy (V/A/W)	≤0.01% FS / ≤0.05% FS / ≤0.02% FS
Ripple (20 Hz–20 MHz)	≤120 mVpp (max ≤300 mVpp)
Efficiency	~93.3%
Power Factor	≥0.99
Input Voltage	342 – 528 V AC (3PH + PE, no neutral)
Max Input Current / Apparent Power	L1,L2/16 A; L3/28 A / 11.1 kVA
Dimensions (W × D × H) / Weight	483 × 801.61 × 151.3 mm / 30 kg
Operating / Storage Temperature	0 – 50°C / -10 – 70°C

Bidirectional DC power supply: source and sink operation
Output: 0–80 V, -450 to +450 A, -15 kW to +15 kW
High efficiency with regenerative energy feedback up to 95%
Multiple communication interfaces: LAN, CAN, USB, I/O, optional RS232/Analog/GPIB
Built-in arbitrary waveform generator and LIST file import via USB
Supports parallel operation for higher power
Built-in automotive and solar simulation functions
Advanced protection: reverse polarity and anti-backflow

SKU: ITEC-IT6015C-80-450
