AMETEK i-BEAM Series

The AMETEK i-BEAM Series includes several high-performance DC power systems. Bidirectional and regenerative, the i-BEAM models provide the power needed for the testing of batteries, DC motors, fuel cell loads, and more. The i-BEAM units have user-friendly features, including high efficiency, air-cooling, and a comprehensive interface.

Product Info Related Products

AC: Input Voltage & Frequency	380/400/440/480/500/690 V ±10%, 3-phase, 50/60 Hz ±6%
AC: Power Consumption	113 kVA
AC: Current (maximum per phase)	181 A at 400 V -10%
DC: Power	35 kW – 650 kW
DC: Voltage	5 – 1000 VDC
DC: Current	±1000 A
Single System Power	Up to 650 kW
Parallel Sytem Power	1.3 MW
Connection Points	Bottom Front, accessible after doors are open
Channel Configurations	1, 2, or 4

Single system power up to 650 kW
Parallel sytem power up to 1.3 MW
Bidirectional output voltage up to 1000 V
Bidirectional output current up to ±1000 A, up to ±2000A in parallel
Available in 1, 2, or 4 channel configurations
Multiple channel units share internal DC bus up to 2MW without drawing additional power from the AC grid
Regenerative to 96%
Large 15-inch color touch panel
Short circuit proof
Designed for safety to EN ISO 13849-1
Dedicated battery testing/simulation modes
Seamless transition between source and sink
High reliability, long life components
