Dimensions |
32.7 x 16.2 x 46.3 cm (12.9 x 6.38 x 18.2 in) |
Weight |
7.0 kg (15.4 lb.) |
Bandwidth |
50 MHz |
Input channels |
2 |
Vertical gain |
5 mV/div to 5 V/div: ±3%
1 mV/div to 2 mV/div: ±5% |
Variable gain (typical) |
1/2.5 or less of the readout indicated value |
Operating temperature |
0° to 40°C |
Operating voltages |
100 V, 120 V, 220 V, 240 V
10% variation from selector range permitted |
Line frequency |
50 or 60 Hz |
Power consumption |
70 VA |
Safety |
Listed CSA C22.2 No. 231 and UL1244 |
