Baker PP30 High Voltage Surge/HiPot Tester

Used Sales Price: $37095
Rent Baker PP30 High Voltage Surge/HiPot Tester
Enlarge Image
Request Quote Print Page
Datasheet
The PP30 Power Pack is a high impulse generator. It is used to test very large high voltage windings. The output is controlled by a variable transformer from 2000 volts up to a maximum of 30,000 volts.

The PP30 performs both surge and DC high potential tests when used with the D12000, D12R or AWA as the control and display. It incorporates a supply monitor to insure safe operation from a well grounded supply. In addition, 60kV rated test lead cables are provided.

Specifications:

Surge Test
Maximum Output Voltage 30,000 Volts
Maximum Output Current w/test leads shorted together:
Three Phase Selector Switch
1400amps - 1500amps
pulse width @ 4 m
Seconds
Single Coaxial Test Lead
1800amps - 1850 amps
pulse width @ 2 m Seconds
Maximum Pulse Energy 45 joules
DC HiPot Potential Test
Maximum Output Voltage 30,000 Volts
Maximum Output Current 1000 mAmps
Overcurrent Trip 10/100/1000 mAmps
Current Resolution 1/10/100 mAmps per div.
