| Temperature range |
Operating: -10 °C to +45 °C (+14 °F to +113 °F)
Storage: -10 °C to +60 °C (+14 °F to +140 °F) |
| Humidity range |
Operating: 0 % to 95 % (32 °F to 95 °F, 0 °C to 35 °C)
RH non-condensing
Storage: 0 % to 95 % (95 °F to 113 °F, 35 °C to 45 °C)
RH non-condensing |
| Altitude |
Operating: 4,000 m (3,200 m with AC adapter)
Storage: 12,000 m |
| Vibration |
2 g, 5 Hz to 500 Hz |
| Shock |
1 meter drop test |
| Safety |
IEC 61010-1: Pollution Degree 2 |
| EMC |
IEC 61326-1: Controlled Electromagnetic Environment; IEC 61326-2-1
CISPR 11: Group 2, Class A
USA (FCC): 47 CFR 15 Intentional Radiators: This device complies with part 15 of the FCC Rules. |
| MPO Endtype Support |
1x8 (8 fibers), 1x12 (8, 10, or 12 fibers), 1x16 (16 fibers), 2x12 (16, 20, or 24 fibers), 2x16 (32 fibers) |
| Test Limits |
IEC 61300-3-35 ED. 2 MM
IEC 61300-3-35 ED. 2 SM APC
Document Only |
| Automated Pass/Fail Test Time |
Less than 2 seconds per fiber |
| Camera type |
5 Megapixel 1/4-inch CMOS sensor |
| Field of view |
610 µm x 460 µm |
| Resolution |
1 µm |
| Light source |
LED, >100,000 hr life |
| Endface illumination |
Coaxial blue LED |
| Port illumination |
White LED |
| Battery Type |
Lithium-ion; 10.8 hour life |
| Power Adapter |
Input: 100 to 240 VAC ±10%, 50/60Hz
Output: 15 VDC, 2 A maximum
Class II |
Wireless
Transmission |
Output power: <100 mW
Frequency ranges: 2.4 GHz (2412 MHz to 2462 MHz) |
| Dimensions |
6.625 in x 5.375 in x 2.125 in (168 mm x 137 mm x 54 mm)
(with no dust cap or adapter tip)
Length with dust cap: 7.5 in (191 mm) |
| Weight |
11.5 oz (326 gm)
(with dust cap and no adapter tip) |
