Ophir 5056F Linear Power RF Amplifier 0.8 GHz - 4.2 GHz

Rent Ophir 5056F Linear Power RF Amplifier 0.8 GHz - 4.2 GHz
Enlarge Image
Rent Ophir 5056F Linear Power RF Amplifier 0.8 GHz - 4.2 GHz Rent Ophir 5056F Linear Power RF Amplifier 0.8 GHz - 4.2 GHz Rent Ophir 5056F Linear Power RF Amplifier 0.8 GHz - 4.2 GHz
Ophir 5056F
Request Quote Print Page
Datasheet
The Ophir 5056F Linear Power RF Amplifier 0.8 GHz - 4.2 GHz is a small and lightweight amplifier utilizes Class A/AB linear power devices that provide an excellent 3rd order intercept point, high gain, and a wide dynamic range. Due to robust engineering and employment of the most advanced devices and components, this amplifier achieves high efficiency operation with proven reliability.

Specifications:


Frequency Range: 0.8 GHz – 4.2 GHz
Saturated Output Power: 1.2 Watts typical
Power Output @ 1dB Comp.: 1.0 Watts min
Small Signal Gain: +30 dB min
Small Signal Gain Flatness: + 2.0 dB max
IP3: +41 dBm typical
Input VSWR: 2:1 max
Harmonics: -20 dBc typical @ 1 Watt
Spurious Signals: > -60 dBc typical @ 1 Watt
Input/Output Impedance: 50 Ohms nominal
