Pacific Power AZX Series

Regenerative AC & DC Power Source | 55 kVA, 55 kW, 3P Models

The Pacific Power AZX Series provides 55 kVA/kW per cabinet, and can scale through parallel operation to 550 kVA/kW, with three-phase configurations available beyond 1.155 MW. Designed for advanced real-time testing, the platform incorporates three high-performance DSPs to support fast transients, complex control loops, and PHIL applications, eliminating the need for external hardware or add-on equipment. Highly configurable output channels, dynamic operating modes, and advanced control and programming features allows the AZX Series to adapt quickly to evolving test requirements. Part of the 3500 AZX series, this particular model has a rated power of 55 kVA and can provide test support to key equipment like grid-connected power generators, electric vehicle chargers, and regulatory compliance test systems.

The 3550AZX is suitable for the following avionics test standards: ABD0100.1.8, ABD0100.1.8.1, AMD24C, Boeing 787B3-0147, DO-160 Section 16, MIL-STD-704, and MIL-STD-1399-300.

Product Info Available Add-Ons Related Compliance Standards Related Products

Frequency Range	DC, 1 - 15 Hz, 15 - 1000 Hz
Accuracy	± 0.005% / 50 ppm
Output Phase Modes	3, 2 & 1
Rated Power AC / DC Mode	55 kVA 55 kW
Voltage Range
Voltage Range	0-240 Vac L-N / 0-415 Vac L-L and 0-480 Vac-LN / 0-830 Vac-LL 0-340 Vdc and 0-680 Vdc
Max. Current	High: 75 / 75 / 225 ARMS 50 / 50 / 150 ADC Low: 130 / 130 / 390 ARMS 100 / 100 / 300 ADC
Dimensions (H x W x L)	59.8” x 24.0" x 31.9" 1520 x 610 x 810 mm
Weight	1140 lb. 517 kg
