Output Power: |
TWT: 40W min |
Flange: 39W min |
Bandwidth: |
8.5 GHz, instantaneous |
Gain at rated power: |
46 dB min |
Gain Control Range: |
20 dB min |
Gain Variation at 6 dB backoff: |
±5 dB over 8.5 GHz, typical |
Gain Stability: |
±0.25 dB/24 hour max at constant drive and temperature (after 1 hour warm up period) |
Input VSWR: |
1.7:1 typical; 2.4:1 max 1.35:1 typical; 1.5:1 max, (with optional input isolator) |
Output VSWR: |
2.0:1 typical; 2.7:1 max |
Load VSWR: |
2.0:1 max; no degradation, infinite VSWR without damage |
