The Fluke 345 Power Quality Clamp Meter is more than an electric power meter. Combining the functions of a clamp meter, oscilloscope, data logger and digital power meter into one handy device, the Fluke 345 is ideal for working with variable frequency motor drives, high efficiency lighting and other loads using switching electronics.
One of the leading wattage meters of the world, the multi-faceted Fluke 345 is packed with features such as a bright, color display to analyze the harmonic spectrum, a low-pass filter to remove high frequency noise and a high EMC immunity design, making the Fluke 345 power analyzer ideal for troubleshooting power quality on switching loads. The internal memory of this electric power meter enables long-term power quality logging for analysis of trends or intermittent problems. Additionally, the Hall Effect clamp meter design makes measurement of dc current possible without the need to break the circuit.
Fluke 345 Features:
- AC/DC current: Clamp-on measurement of ac current up to 1400 A rms and dc current up to 2000 A without breaking the circuit
- Highest safety rating: 600 V CAT IV power analyzer is rated for use at the service entrance
- Accurate in noisy environments: Clamp meter performs even with distorted waveforms present on electronic loads with low-pass filter
- Data logging: Identify intermittent faults by logging any power quality parameter for minutes, or over a month, including harmonics
- Verify batteries: Direct measurement of dc ripple (%) for battery and dc systems
- Troubleshoot harmonics: Analyze and log harmonics digitally or graphically
- Inrush current: Capture and analyze nuisance tripping, from 3 seconds to 300 seconds
- Easy to use: Easily confirm power meter setup with large backlit color display of waveforms and trends
- 3-Phase power: Built in capability for balanced loads
- View graphs and generate reports: Use power analyzer with included Power Log software
