Fluke 43B 1-Phase Power/Harmonics Analyzer to 600V/500A

Used Sales Price: $3098.95
Rent Fluke 43B 1-Phase Power/Harmonics Analyzer to 600V/500A
Enlarge Image
Rent Fluke 43B 1-Phase Power/Harmonics Analyzer to 600V/500A Rent Fluke 43B 1-Phase Power/Harmonics Analyzer to 600V/500A Rent Fluke 43B 1-Phase Power/Harmonics Analyzer to 600V/500A
Request Quote Print Page
Manual Other1

The Fluke 43B Power Quality Analyzer combines the most useful capabilities of a power quality analyzer, scope and multimeter in a single easy-to-use instrument.


Features:

  • Displays voltage, current and power waveforms
  • Measures RMS, Peak and Total Harmonic Distortion of voltage and current
  • Displays harmonic detail in bar graph format
  • Measures harmonic power and indicates direction of flow
  • Records Min/Max/Avg readings of voltage, current, power and frequency
  • Optically isolated RS-232 interface
  • FlukeView® PC software for Windows® and DOS included
  • Harmonics to 51st
  • Total power factor (PF)
  • Displacement power factor (DPF)
  • K-factor (A & W): 1 - 30
  • Phase angle of fundamental and harmonics
  • Waveform and spectrum displays
  • Record mode - MIN, MAX and AVG
  • Handheld, 1 kg (2 lb)




Specifications:

True-rms (AC & DC) Voltage 5.0 V - 1250 V
True-rms (AC & DC) Current 50 A - 1250 kA
Frequency 10 Hz - 15 kHz
CF Crest Factor 1 - 10
Power W, VA, VAR, Reactive Power 1-phase & 3-phase, 3 conductor balanced loads; 250 W - 1.56 GW
