| Models |
310, 350, 5100 |
| Size Range |
Model 310: 0.3 - 25.0 µm
Model 350: 0.3 - 25.0 µm
Model 5100: 0.5 - 25.0 µm |
| Flow Rate |
Model 310: 28.3 LPM (1.0 CFM) ±5%
Model 350: 50 LPM ±5%
Model 5100: 100 LPM ±5% |
| Zero Count |
Model 310: <7.07 counts / m3
Model 350: <4.00 counts / m3
Model 5100: <2.00 counts counts / m3 |
| Maximum Concentration |
Model 310: >42,924,662 / m3
Model 350: >28,209,736 / m3
Model 5100: >21,354,726 / m3 |
| Channels |
Up to 8 configurable channels
Optional 2-channel pharmaceutical mode |
| Counting Efficiency |
50% ± 20% for most sensitive channel
ISO 21501-4:2018 compliant |
| Compressed Gas |
Air (CDA), argon (Ar), nitrogen (N), and carbon dioxide (CO2)
Requires HPD III accessory |
| Display & Printer |
8.4-inch color SVGA display, p-cap with finger swipe and gesture control
Optional built-in thermal printer with paper cutter
Supports cleanroom paper |
| Operating Temperature |
0 - 32°C (32 - 89.6°F) |
| Dimensions |
24.6 x 25.7 x 25.6 cm (9.7 x 10.1 x 10.1 in) |
| Weight |
6.4 kg (14.2 lb.) with two optional batteries
5.4 kg (11.9 lb.) without batteries |
