Phenix Technologies 4100-10 Portable DC Hipot 100 kVDC

Rent Phenix Technologies 4100-10 Portable DC Hipot 100 kVDC
Enlarge Image
Request Quote Print Page
Datasheet
The Phenix Technologies 4100-10 Portable DC Hipot 100 kVDC is lightweight, compact, and ruggedly built for use in the lab or field for accurate testing of electrical switchgear, cables, motors, generators, and protective equipment. It includes many advanced features including high accuracy digital meters, analog charging current meter, adjustable overcurrent, and increased output current ratings.

Features:


  • Line weight, portable and enclosed in rugged, polyethylene carrying case
  • Output voltage continuously adjustable
  • "Zero Start" Interlock
  • Integrated cable storage bin
  • Adjustable overcurrent trip point from 10%-110% of each current range
  • Thermal resettable overload
  • Large, easy to read, high accuracy digital meters
  • Input Circuit Breaker/Power Switch
  • Analog 0-100% of range current meter for visual charge indication
  • Built in discharge circuit
  • Removable line cord

Specifications:


Input: Voltage/Current 110-120 V, 10 A
220-240 V, 5 A
Frequency 50/60 Hz
Output: Voltage/Current 0-100 kV, 10 mA
Ripple <2%
Polarity negative output, positive ground
