The PMM AS-04 is a compact broadband antenna system composed of a PMM BC-01 Biconical Dipole and LP-04 Log Periodic Dipole Array designed for radiated emissions and immunity testing. The PMM AS-04 can be used in conjunction with any receiver or spectrum analyzer. The ideal companion for the PMM AS-04 is the PMM 9060 30 MHz - 6 GHz EMC/EMI receiver that can be easily mounted on the antenna mast.

	BC-01	LP-04
Frequency range	30 to 200 MHz	200 MHz to 6 GHz
Gain	-15 +2 dBi typical	6 dBi typical
Antenna factor	8 to 14 dB/m typical	12 to 40 dB/m typical
Max input power	100 W	100 W
Connector	N-female	N-female
Dimensions (L x H x W)	65 x 65 x 137 cm	78 x 10 x 75 cm
Weight	1.8 kg	1.1 kg
