Teseq LD 5505 Load Dump Generator

  Tech Support
(800) 404-2832
ATEC Assurance With Every
Load Dump pulses simulate the sudden disconnection (e.g. by corrosion) of the battery from the alternator while the alternator is generating current to load the battery. Such pulses have high energy with a high potential of destruction. These pulses having duration time in the range of hundreds of milliseconds. By means of a built-in clipping circuit and battery switch, the LD 200N100 also generates negative- and clipped load dump pulses as per international standards as well as manufacturer requirements.
