| Model |
2560A |
| DC Voltage Range |
100 mV, 1 V, 10 V, 100 V, 1000 V |
| DC Voltage Accuracy |
±50 ppm (180 days) |
| DC Current Range |
100 μA, 1 mA, 10 mA, 100 mA, 1 A, 10 A, 30 A |
| DC Current Accuracy |
±70 ppm (180 days) |
| Resistance Generation |
1 to 400 Ω |
| Operating Temperature |
+5°C to +40°C (+41°F to +104°F) |
| Storage Temperature |
-15°C to +60°C (+5°F to +140°F) |
| Dimensions (W x H x D) |
426 x 177 x 400 mm (16.8 x 7.0 x 15.7 in) |
| Weight |
Approx. 13 kg (28.7 lb.) |
