Yokogawa LS3300 AC Power Calibrator

The Yokogawa LS3300 AC Power Calibrator is a highly accurate device with single to three phase power calibration capabilities. With an LCD display, a stabilizing function, and short calibration times, the LS3300 is the ideal model for a variety of testing requirements. This model can be used to output current and voltage simultaneously. Easy-to-use and precise, the LS3300 allows for in-depth and effective calibration.

Product Info Related Products

Model	LS3300
AC Power Accuracy	±450 ppm
AC Voltage	Guaranteed accuracy range: 10 mV to 1250 V Accuracy 50/60 Hz: ±350 ppm
AC Current	Guaranteed accuracy range: 0.3 mA to 62.5 A Accuracy 50/60 Hz: ±450 ppm
Frequency Output Range	40 to 1200 Hz
Power Stability	±100 ppm
Maximum Output	Approx. 36 VA
Dimensions (W x H x D)	426 × 132 × 450 mm (16.8 x 5.2 x 17.7 in)

Delivers best-in-class power accuracy of ±450 ppm
High output current of 62.5 A
Designed to meet the high stability and accuracy needed for testing power meters
Flexibility of single to three phase calibration and a suite of features for power meter validation
Efficient, expeditious calibration

SKU: YOKO-LS3300
