Narda EHP-200A Electric & Magnetic Field Analyzer | 9 kHz - 30 MHz
- Control via PC software or via an optional display unit
- Auxiliary connection for spectrum analysis of external signals
- Separate display of field strength for the three axes and the overall value
Narda SRM-3006 Selective Radiation Meter | 9 kHz - 6 GHz
- Measurements conforming to ICNIRP and national standards with results displayed directly in terms of the permitted limit value
- Fast, reliable results using predefined measurement routines, setups, and automatic settings
- LTE and UMTS operating modes for evaluating pilot signal information and extrapolation to maximum exposure levels
Narda EF 0391 NBM E-Field Probe, 2402/01B | 100 kHz - 3 GHz
- General public and occupational field exposure from broadcasting, telecoms and industrial equipment
- Isotropic (non-directional) measurement
- 64 dB dynamic range without changing measurement range
Wavecontrol WPT Field Probe
- Specific mobile frequencies probe
- Isotropic & True RMS measurement
- Best sensitivity starting at 0.04 V/m
Narda HF 3061 NBM H-Field Probe | 300 kHz - 30 MHz
- Public and occupational field exposure from broadcasting, telecoms, and industrial equipment
- Isotropic (non-directional) measurement
- 62 dB dynamic range without changing measurement range
Wavecontrol WP400 Probe | 1 Hz - 400 kHz
- Electric & Magnetic field measurement
- Isotropic & True RMS measurement
- Spectrum analysis probe
Narda EF 4091 NBM E-Field Probe | 40 MHz - 40 GHz
- General public and occupational field exposure
- Broad frequency range with high dynamic range
- Isotropic (non-directional) measurement
Narda EF 6091 NBM E-Field Probe | 100 MHz - 60 GHz
- Flat frequency response
- Thermocouple sensors
- True RMS measurement, even with pulsed signals
Wavecontrol SMP2 Electromagnetic Field Meter
- 3-in-1 field meter
- Total field value and value for each component (X, Y, Z)
- Broadband measurements: 0 Hz - 60 GHz With RMS and isotropic field probes
Narda 5G FR2 Antenna - Directional & Omnidirectional (3591/103) | 24.25 - 29.5 GHz
- Extends SRM-3006 to cover 24.25 GHz to 29.5 GHz
- Calibrated antennas for reliable measurements
- Measurements are displayed in field strength or in percent of limit values
Narda NBM-520 Broadband Field Meter, 2403/01B | 100 kHz - 60 GHz
- Automatic probe type recognition
- Intelligent probes (automatic probe data transfer)
- Audible alarm function
_53.jpg)
Narda HF 0191 NBM H-Field Probe | 27 MHz - 1 GHz
- Occupational field exposure from radio broadcasting, telecoms, industrial equipment
- Isotropic (non-directional) measurement
- Dynamic range 59 dB without changing measurement range
Narda 5G FR2 Antenna for SRM 3006 - Omnidirectional (3591/02) | 24.25 GHz - 29.5 GHz
- Extends SRM-3006 to cover 24.25 GHz to 29.5 GHz
- Calibrated antennas for reliable measurements
- Measurements are displayed in field strength or in percent of limit values, e.g. ICNIRP, FCC...
Wavecontrol WPF6 Probe | 100 kHz to 6 GHz
- High sensitivity from 0.2 V/m
- Isotropic & True RMS measurement
- Excellent attenuation at 50/60 Hz
WaveControl WP10M Low Frequency H and E Field Probe
- Electric & Magnetic field measurement
- Isotropic & True RMS measurement
- Spectrum analysis probe
Narda EF 0392 NBM E-Field Probe, 2402/12B | 100 kHz - 3 GHz
- General public and occupational field exposure from broadcasting, telecoms and industrial equipment
- Isotropic (non-directional) measurement
- 64 dB dynamic range without changing measurement range
Narda EA 5091 E-Field Shaped Frequency Probe, 2402/07B | 300 kHz - 50 GHz
- Measurement range: 0.5 to 600% of FCC "Occupational/Controlled limits"
- Linearity: +/- 3 dB (0.5 to 6%)
- +/- 1 dB (6 to 100%)
Narda NIM-511 Industrial Field Meter | 300 kHz - 100 MHz
- Complete Measurement System with dual electrical and magnetic field probe for frequencies up to 100 MHz
- Covers for example most industrial equipment, RF heat sealers and vinyl welders, Semiconductor Process Equipment and glass deposition, RF induction heating, dielectric dryers, heaters, or plasma
- Isotropic sensor
Wavecontrol WPF18 Probe | 300 kHz to 18 GHz
- Electric field measurement
- Isotropic & True RMS measurement
- High sensitivity from 0.5 V/m
Narda EF 9091 NBM E-Field Probe | 100 MHz - 90 GHz
- General public and occupational field exposure
- Broad frequency range with high dynamic range
- Isotropic (non-directional) measurement
Narda 3502/01 3-Axis Isotropic Antenna | 27 MHz - 3 GHz
- Measures electric field
- Isotropic characteristic
- Stored calibration factors, applied automatically
Narda EHP-50F E&H-Field Analyzer | 1 Hz - 400 kHz
- Conforms to EMF Directive 2013/25/EU
- Weighted Peak method for capturing complex signal shapes
- FFT spectrum analysis for E-field and H-field in one device
Narda NBM-580 Broadband Radiation Meter, 2400/801B
- Up to 8 Input Metering Station for NBM Meters and/or NS3 Monitors
- Allows Central Control Of Multiple Field Sensors
- Built-in, Low and High Power Alarm Relays
Narda EF 0692 E-Field Probe, 2402/20B | 600 MHz - 6 GHz
- Flat frequency response with suppression of fields below 600 MHz
- Diode sensors
- Isotropic characteristic
Wavecontrol WP50 Probe | 10 Hz - 3 kHz
- Electric & Magnetic field measurament
- Isotropic & True RMS measurement
- Probe weighted dependant on the selected limit
