Fluke 2620A
Request Quote Print Page
Manual
21 Ch Logging Data Scanner (Wireless Available)

Fluke 2620A Features
  • 21 analog input channels
  • Measures Vdc, Vac, thermocouples, RTDs, resistance, and frequency
  • Standard RS-232C interface
  • Easy set up through front panel or remotely via PC
  • Application software for PC included: Hydra Starter Package
  • AC or DC operation enables Hydra to work where line power is not available
Fluke 2620A Specs
  • Channel Capacity: Analog Inputs: 21; Digital I/O & Alarm Outputs: 12 total; Totalizer: 1
  • MEASUREMENT
    DC Voltage Range: 100mV - 150V, 300V
    DC Voltage Resolution: 1µV
    Resistance: 300 ohms to 10 M ohms
    Resistance Resolution: 10 M ohms to K ohms
    AC Voltage (True rms, ac coupled): 300mV - 150V, 300V
  • Thermocouples: Type J, K, N, E, T, R, S, B, C
  • DC Current: 4-20mA
  • 2625A Data Storage: stores 2047 scans
  • 2635A Data Storage (in scans): 2047
  • RTD (Pt 100)
    Resolution Slow: 0.02 °C (temp)
    Resolution Fast: 0.1 °C (temp)
  • Frequency
    Range: 15 Hz - 1MHz
    Resolution: 0.01Hz - 1KHz
Fluke 2620A Accessories
Optional Accessories:
  • GPIB IEEE-488 interface
