HP Agilent 3585A Spectrum Analyzer, 20Hz - 40MHz

HP/Agilent 3585A Spectrum Analyzer
Enlarge Image
Request Quote Print Page
Manual

Features:

  • 80 dB dynamic range
  • 3 Hz resolution bandwidth
  • ±0.4 dB amplitude accuracy
  • 1001 x 970 Digital Storage Display



Specifications:

Frequency
  • Measurement Range: 20 Hz to 40.1 MHz
  • Displayed Frequency Span - Range: 0 Hz to 40.1 MHz
  • Displayed Center, Start/Stop, and Manual Frequency - Range: 0 Hz to 40.1 MHz
  • Marker: Readout; Counter
  • Resolution Bandwidths - Range: 3 dB bandwidth of 3 Hz to 30 kHz in a 1, 3, 10 sequence

Amplitude
  • Measurement Range
    • 1 M ohms input: -31 nVrms to +7.08 Vrms
    • 50/75 ohms input: -137 dBm to +30 dBm
