Chroma 63208 DC Electrical Load 80 V, 60 A, 1560 Watts

Rent Chroma 63208 DC Electrical Load 80 V, 60 A, 1560 Watts
Enlarge Image
Request Quote Print Page
Datasheet
The Chroma 63208 DC Electrical Load 80 V, 60 A, 1560 Watts is designed for DC power source, power electronic devices and components testing. The high power rating, parallel and synchronization capabilities make it the ideal tool for testing the high power UUT such as SMR,UPS, battery, and fuel cell. The 63208 offers a power range up to 1560 watts, current up to 60 A and up to 80 V input voltage. The 4 load modes setup provide different load simulations for various application occasions. The CC/CR modes are designed to test constant voltage type of power supply. CV mode is used to test battery charger and current source, while CP mode is ideal for battery testing by simulating the real discharge curve.

Specifications:


Constant Current Mode
Range: 0-60A
Resolution: 15mA
Overload: 0.1%+0.2%F.S.
Constant Resistance Mode
Range: 0.0025-10ohm
Resolution: 12bits
Accuracy: 1.2mho+0.35%
Constant Voltage Mode
Range: 1-16V
Resolution: 4mV
Accuracy: 0.05%+0.1%F.S.
Constant Power Mode
Range: 0.6-260W
Resolution: 7.5mW
Accuracy: 0.5%+0.5%F.S.
