The RIGOL RSA5065N Real-Time Spectrum Analyzer is a high-speed instrument with a frequency range of 9 kHz to 6.5 GHz. Part of the RSA5000 Series, the RSA5065N includes a General-Purpose Spectrum Analyzer (GPSA), Real-time Spectrum Analyzer (RTSA), and Vector Network Analyzer Application(VNA), along with a tracking generator mode and additional options. The RIGOL RSA5065N Real-Time Spectrum Analyzer is a flexible and innovative device, allowing technicians to meet several different testing requirements.

Specifications
Features
Applications
Options
Accessories
Standards
Videos

Frequency range	9 kHz - 6.5 GHz
Dimensions (W x H x L)	16.14 in × 8.82 in × 5.32 in 410 mm × 224 mm × 135 mm
Weight	Without tracking generator: 4.65 kg (10.25 lb.) With tracking generator: 4.95 kg (10.91 lb.)
Operating temperature	0°C to +50°C
Storage temperature	-20°C to +70°C
Display	Capacitive multi-touch screen 1024 × 600 pixels 10.1'' 24-bit color
Power consumption	55 W (typical), max. 90 W with all options
Real-time bandwidth	25 MHz (40 MHz option)
Modes	GPSA RTSA VNA Tracking Generator VSA (optional) EMI (optional)
