| Frequency Range |
9 kHz to 8 GHz |
| Frequency Accuracy |
≤ ± 5 ppm @ 25 °C |
| Frequency Resolution |
1 Hz |
| Return Loss |
0 dB ≤ return loss < 15 dB nominal < 3°
15 dB ≤ return loss < 25 dB nominal < 6°
25 dB ≤ return loss < 35 dB nominal < 20° |
| DC Voltage |
80 V |
| Frequency Range |
15 MHz - 3.0 GHz |
| Display Range |
displayed noise floor to +30 dBm |
| Measurement Range |
–60 dBm < PRF channel < 20 dBm |
| Offset Range Max |
± 100 dB, user settable value |
| Measurements |
Return Loss
VSWR
Cable Loss
Distance-to-Fault RL
Distance-to-Fault VSWR
RF Power |
| Internal Trace Storage |
> 256 instrument settings and traces |
| External Trace Storage |
Limited only by size of USB Flash drive |
| Connectivity |
(2) USB 2.0 Type A, Interface: Type mini-B, Connect to PC for data transfer |
| Display |
SNR > 16 dB, 0 dB to –50 dB, logarithmic level display |
| Temperature |
Operating Temperature 0 °C to +40 °C |
| Battery |
Li-ion > 8.0 hours typical |
| Dimensions |
194 mm × 300 mm × 144 mm
(7.6 in × 11.8 in × 5.7 in) |
| Weight |
< 3 kg (< 6.6 lb) |
