Dimensions
(L x W x H) |
163 x 83 x 41 mm (6.42 x 3.27 x 1.61 in) |
| Weight |
350 g |
| Accuracy |
Voltage DC: 0.01%RD + 2mV
Current DC: 0.01%RD + 2µA |
| Measurement functions |
Auto step
Auto ramp
Span step |
| Loop power |
24 V |
| Over-voltage protection |
30 V DC (240 V AC) |
| Overload current protection |
33 mA DC |
| Storage temperature |
-20°C to 70°C (-28.9 to 21.1°F) |
| Operating temperature |
-10 to 50°C (-23.3 to 10°F) |
| Working altitude |
<3,000 m |
| Calibration certification |
ISO 17025 |
| Display |
VA LCD display
2.04 x 2.04 in (52 x 52 mm) |
